Tape Storage Products
Spectra Stack Library
Uncompromising flexibility meets affordability in a modular entry-level library with enterprise-class features
The only stackable system designed for 24x7 continuous operation – smart indeed
Spectra Stack libraries are designed for growing enterprises and growing data. From a single control module to as many as six expansion modules, Spectra Stack solutions deliver the right capacity and performance at every stage of growth. Its remarkable 100% duty cycle makes it an ideal choice for handling unanticipated or dynamic workloads with ease.
Spectra Stack Front View
Spectra Stack Back View
Spectra Stack Front View
Spectra Stack Back View
Menu
Specifications at a glance
| Capacity & Throughput | |||||||
|---|---|---|---|---|---|---|---|
| # Control Modules | # Expansion Modules | |||||||
| Max Slot Count | Media Type | |||||||
| Max Native Capacity1 | |||||||
| Max Compressed Capacity1, 2 | |||||||
| Max Drives | |||||||
| Max Native Throughput1 (TB/hr.) | |||||||
| Max Compressed Throughput1 (TB/hr.) | |||||||
| Max SLS Partitions | |||||||
| Tape Drives Supported | |||||||
| 1. Stated maximums based on exclusive use of full height LTO-9 drives. 2. LTO-9 assumed compression ratio is 2.5:1. |
|||||||
| Environmentals – All LTO Drives | |||||
|---|---|---|---|---|---|
| Mode | Dry-bulb Temperature | Maximum Temperature Rate of Change | Relative Humidity (non-condensing) | Maximum Humidity Rate of Change | Altitude (max) |
| Allowable Environment | 16°C to 32°C (60°F to 90°F) | 5°C per hour 9°F per hour | 20% to 80% 22°C dew point max | 5% per hour with no condensation | 3048 m (10,000 ft) |
| Recommended Environment | 16°C to 25°C (60°F to 77°F) | 5°C per hour 9°F per hour | 20% to 50% 22°C dew point max | 5% per hour with no condensation | 3048 m (10,000 ft) |
| Reliability | |
|---|---|
| Library MTTR | 3 minutes for hot-swap components. 10 minutes for non-hot-swap components Mean Cycles Between Failures (MCBF): 3 million Mean Time Between Failures (MTBF): 250,000 power-on hours |
| Power Requirements | 100-240v AC, 50/60Hz 80 PLUS Gold Power Supplies. |
| Library Features | |
|---|---|
| Encryption Supported | BlueVision |
| Media Lifecycle Management | Yes |
| Auto Clean Support | Yes |
| Camera (Spectra Vision) | Yes |
| Tape Technology Supported | LTO-5 | LTO-6 | LTO-7 | LTO-7 Type M | LTO-8 | LTO-9 |
| Control Module | Expansion Module | |
|---|---|---|
| Width | 18.7 in (475 mm) | 18.7 in (475 mm) |
| Depth | 35.12 in (892 mm) | 35.12 in (892 mm) |
| Height | 10.55 in (268 mm) | 10.55 in (268 mm) |
| Weight | 78.26 lb (35.5 kg) | 68.34 lb (31 kg) |
